Honda CB500X - Left Side Cover

Left Side Cover
#
Removal
1.
Remove the seat. 2 P. 75
2.
Remove the bolt.
3.
Remove the prongs from the grommets,
then remove the left side cover backward
by releasing the hooks.
#
Installation
Install the parts in the reverse order of
removal.
20190308105638_42MKPC000_eng_BOOK Page 79 Friday, March 08 2019 11:02:25 JST
Removing & Installing Body Components u Left Side Cover
Maintenance
76
Left side cover
Bolt
Grommets
Prongs
Hooks
Hook
