Brakes
Checking Brake Fluid
1.
Place your motorcycle in an upright
position on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
is horizontal and that the fluid level is
above the LWR mark.
Rear
Check that the brake fluid reservoir
is horizontal and that the fluid level is
between the LOWER level and UPPER
level marks.
If the brake fluid level in either reservoir is
below the LWR mark or LOWER level mark or
the brake lever and pedal freeplay becomes
excessive, inspect the brake pads for wear.
If the brake pads are not worn, you most
likely have a leak. Have your motorcycle
inspected by your dealer.
20190308105638_42MKPC000_eng_BOOK Page 86 Friday, March 08 2019 11:02:25 JST
Maintenance
83
Front brake fluid reservoir
LWR mark
UPPER level
mark
LOWER level
mark
Rear brake fluid reservoir
Front Rear
