7.
Apply a thin coat of engine oil to the
rubber seal of a new oil filter.
8.
Install a new oil filter and tighten.
9.
Install a new sealing washer onto the
drain bolt. Tighten the drain bolt.
10.
Fill the crankcase with the recommended
oil (2 P. 50) and install the oil fill cap/
dipstick.
11.
Check the oil level. 2 P. 61
12.
Check that there are no oil leaks.
Torque: 26 N·m (2.7 kgf·m, 19 lbf·ft).
Torque: 30 N·m (3.1 kgf·m, 22 lbf·ft).
Required oil
When changing oil &
engine oil filter:
2.9 litres (3.1 US qt, 2.6 Imp qt)
When changing oil only:
2.6 litres (2.7 US qt, 2.3 Imp qt)
14 CB650F FA (NK)-32MJED000.book 64 ページ ２０１３年１２月２３日 月曜日 午後６時２分
