Honda CB650F User Manual

Engine Oil u Changing Engine Oil & Filter
63
continued
Maintenance
Changing Engine Oil & Filter
Changing the oil and filter requires special
tools. We recommend that you have your
motorcycle serviced by your dealer.
Use a new Honda Genuine oil filter or
equivalent specified for your model.
1. If the engine is cold, idle the engine for 3
to 5 minutes.
2. Turn the ignition switch off, stop the
engine and wait for 2 to 3 minutes.
3. Park on a firm, level surface and lower
the side stand.
4. Place a drain pan under the drain bolt.
5. Remove the oil fill cap/dipstick, drain
bolt, and sealing washer to drain the oil.
6. Remove the oil filter with a filter wrench
and let the remaining oil drain out. Make
sure the prior seal is not stuck to the
engine.
u Discard the oil and oil filter at an
approved recycling centre.
NOTICE
Using the wrong oil filter can result in serious damage to
the engine.
Sealing washer
Drain bolt
14 CB650F FA (NK)-32MJED000.book 63 ページ ２０１３年１２月２３日 月曜日 午後６時２分
Honda CB650F Owner's Manual
http://www.motorcycle.in.th

Honda CB650F Specifications

General

Torque	63 Nm @ 8, 000 rpm
Transmission	6-speed
Fuel System	PGM-FI electronic fuel injection
Front Suspension	41mm telescopic fork
Front Brakes	Dual 320mm discs with two-piston calipers
Rear Brakes	Single 240mm disc with single-piston caliper
Seat Height	810 mm
Fuel Capacity	17.3 liters
Curb Weight	208 kg
Bore x Stroke	67 mm x 46 mm
Compression Ratio	11.4:1
Max Torque	63 Nm @ 8, 000 rpm
Starter	Electric
Final Drive	Chain
Width	775 mm
Ground Clearance	150 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, inline 4-cylinder
Power	64 kW (87 PS) @ 11, 000 rpm
Rear Suspension	Monoshock damper with adjustable preload
Max Power Output	64 kW (87 PS) @ 11, 000 rpm
Ignition System	Digital transistorized
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Length	2110 mm
Wheelbase	1, 450 mm
Height	1120 mm
