Installation
1.
Attach the side collars to the wheel.
2.
On the left side, place the wheel between
the fork legs and insert the lightly greased
front axle shaft to the end, through the
left fork leg and wheel hub.
3.
Align the end of the front axle shaft with
the surface of the fork leg.
4.
Tighten the left axle pinch bolt to hold
the axle.
5.
Tighten the axle bolt.
6.
Loosen the left axle pinch bolt.
7.
Tighten the right axle pinch bolt.
8.
Secure the wheel speed sensor wire with
the clamp.
9.
Install the right brake caliper and tighten
new mounting bolts.
Torque: 59 N·m (6.0 kgf·m, 44 lbf·ft).
Torque: 22 N·m (2.2 kgf·m, 16 lbf·ft).
Torque: 30 N·m (3.1 kgf·m, 22 lbf·ft).
