30
FUEL
Fuel tank
The fuel tank is equipped with an automatic
vacuum valve.
The fuel supply is assured whenever the engine
is started and suspended as soon as the engine
is stopped.
Fuel tank capacity inclusive of reserve capacity
is:
19.0 l
Reserve capacity is:
3.5 l
To open the fuel fill cap (1), insert the ignition
key (2) and turn it clockwise. The fuel fill cap
will pop up and can be lifted off.
Do not overfill the tank. There should be no
fuel in the filler neck (3).
After refueling, to close the fuel fill cap, push
the fuel fill cap into the filler neck until it snaps
closed and locks. Remove the key.
(1) Fuel fill cap
(2) Ignition key
(3) Filler neck
(1)
(2)
(3)
n
WARNING
Petrol is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.
Stop the engine and keep heat, sparks,
and flame away.
Refluel only outddors.
Wipe up spills immediately.
