Honda CBF600S 2006 User Manual

111
Battery Removal:
The battery (1) is in the battery box behind the
right side cover
1. Remove the right side cover(page 53).
2. Remove the rider seat. (page 49).
3. Unhook the strap (2).
4. First disconnect the negative (-) terminal
lead (3) from the battery, then disconnect
the positive (+) terminal lead (4).
5. Pull out the battery from the battery box (5).
To reassemble the battery:
When reassembling the battery, make sure
you feed the siphon (6), vent tube (7), drain
tube(8), positive battery terminal wire (+) (9)
and negative battery terminal wire (-) (10)
under the belt (2) as shown in the drawing on
page 112.
(1) Battery
(2) Strap
(3) Negative (-) terminal lead
(4) Positive (+) terminal lead
(5) Battery box
(1)
(2)
(3)
(4)
(5)

Honda CBF600S 2006 Specifications

General

Displacement	599 cc
Compression Ratio	11.6:1
Fuel System	PGM-FI electronic fuel injection
Starting	Electric
Transmission	6-speed
Clutch	Wet, multi-plate
Final Drive	O-ring sealed chain
Front Suspension	41 mm telescopic fork, 120 mm travel
Front Brakes	Dual 296 mm discs with 2-piston calipers
Engine Type	Liquid-cooled, 4-stroke, inline-four
Bore x Stroke	65.0 mm x 45.2 mm
Max Power	57 kW / 9, 500 rpm (95/1/EC)
Ignition	Digital transistorized with electronic advance
Rear Brakes	Single 240 mm disc with 1-piston caliper
Front Tire	120/70ZR17
Rear Tire	160/60ZR17
Fuel Capacity	19 liters (5.0 US gallons)
