Honda CBR600RR User Manual

Keys
101
Information
Keys
The ignition key contains a special coded chip
that is recognized by the immobilizer system
(HISS) in order to start the engine. Handle the
key carefully to prevent damaging the HISS
components.
● Do not bend keys or subject them to undue
stress.
● Avoid prolonged exposure to sunlight or high
temperatures.
● Do not grind, drill or in any way alter their
shape.
● Do not expose to strong magnetic objects.
If you lose all keys and the key number plate,
the PGM-FI unit/ignition control module must
be replaced by your dealer. To avoid this, keep
a duplicate key.
If you lose a key, make another duplicate key
immediately.
To make a duplicate key and register it with
your HISS system, take the spare key, the key
number plate, and the motorcycle to your
dealer.
A metal key holder may cause damage to the
area surrounding the ignition switch.
Ignition key
13 CBR600RR-32MJC6000.book 101 ページ ２０１３年１月２９日 火曜日 午前１１時５０分

Honda CBR600RR Specifications

General

Engine Type	599cc liquid-cooled inline four-cylinder
Bore and Stroke	67.0mm x 42.5mm
Compression Ratio	12.2:1
Ignition	Computer-controlled digital transistorized with electronic advance
Final Drive	#525 O-ring-sealed chain
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability; 5.1 inches travel
Front Brake	Dual radial-mounted four-piston calipers with 310mm discs
Rear Brake	Single 220mm disc
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
Rake	23.5 degrees
Wheelbase	53.9 inches
Seat Height	32.3 inches
Curb Weight	410 pounds
Fuel Capacity	4.8 gallons
Induction	PGM-DSFI
Transmission	6-speed
Front Suspension	41mm inverted with spring preload, rebound and compression damping adjustability; 4.3 inches travel
