Honda CBR600RR User Manual

Riding Precautions
13
continued
Motorcycle Safety
❙
Combined ABS (CBR600RA)
Even when the brake lever and brake pedal are
applied separately, the combined ABS
distributes braking between the front and rear
wheels according to braking force and wheel
speed. The integrated system controls wheel
lockup when the brake is applied with too
much force heading in a straight line.
To get the best results out of the system,
operate the lever and pedal together.
Always ride the specified tyres on both front
and rear wheels to ensure correct operation of
the combined ABS.
● The combined ABS cannot make up for road
surfaces, weather conditions, bad judgement
or incorrect operation of the brakes, and
cannot stop rear wheel lift.
u Always ride safely at the appropriate speed
according to weather conditions and road
surfaces.
● The system does not reduce stopping
distance.
u The same stopping distance without the
tyres slipping is required as for a
motorcycle not equipped with ABS.
● At low speed (approximately 6 km/h (4 mph)
or less), braking operates without combined
ABS.
● The combined ABS does not operate when
the battery level is low.
● The combined ABS does not operate when
the ABS main fuse or ABS motor fuse is
burned out.
You may feel a change in the way the brake
lever/pedal reacts when it is operated under the
following conditions:
● Immediately after turning the ignition switch
to ON.
● After braking to a stop and applying the
brakes again.
13 CBR600RR-32MJC6000.book 13 ページ ２０１３年１月２９日 火曜日 午前１１時５０分

Honda CBR600RR Specifications

General

Engine Type	599cc liquid-cooled inline four-cylinder
Bore and Stroke	67.0mm x 42.5mm
Compression Ratio	12.2:1
Ignition	Computer-controlled digital transistorized with electronic advance
Final Drive	#525 O-ring-sealed chain
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability; 5.1 inches travel
Front Brake	Dual radial-mounted four-piston calipers with 310mm discs
Rear Brake	Single 220mm disc
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
Rake	23.5 degrees
Wheelbase	53.9 inches
Seat Height	32.3 inches
Curb Weight	410 pounds
Fuel Capacity	4.8 gallons
Induction	PGM-DSFI
Transmission	6-speed
Front Suspension	41mm inverted with spring preload, rebound and compression damping adjustability; 4.3 inches travel
