Honda CBR600RR User Manual

Specifications
116
Specifications
■ Bulbs
■ Fuses
■ Torque Specifications
Recommended drive
chain lubricant
Drive chain lubricant designed specifically
for O-ring chains
Drive chain slack 30 to 40 mm (1.2 to 1.6 in)
Standard drive chain
DID 525HV or RK 525ROZ6
No. of links 112
Standard sprocket
sizes
Engine sprocket 16T
Rear wheel
sprocket
41T
Headlight 12V-55W × 2
Brake/Tail light LED
Front turn signal/
Position lights
12V-21/5 × 2
Rear turn signal lights 12V-21W × 2
License plate light 12V-5W
Main fuse 30A
Other fuses
CBR600RR 20A, 10A
CBR600RA 30A, 20A, 10A
Engine oil drain bolt 30 N·m (3.1 kgf·m, 22 lbf·ft)
Oil filter 26 N·m (2.7 kgf·m, 19 lbf·ft)
Front wheel axle bolt 59 N·m (6.0 kgf·m, 44 lbf·ft)
Front wheel brake caliper
mounting bolts
45 N·m (4.6 kgf·m, 33 lbf·ft)
Front wheel axle pinch bolts 22 N·m (2.2 kgf·m, 16 lbf·ft)
Rear wheel nuts 113 N·m (11.5 kgf·m, 83 lbf·ft)
13 CBR600RR-32MJC6000.book 116 ページ ２０１３年１月２９日 火曜日 午前１１時５０分

Honda CBR600RR Specifications

General

Engine Type	599cc liquid-cooled inline four-cylinder
Bore and Stroke	67.0mm x 42.5mm
Compression Ratio	12.2:1
Ignition	Computer-controlled digital transistorized with electronic advance
Final Drive	#525 O-ring-sealed chain
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability; 5.1 inches travel
Front Brake	Dual radial-mounted four-piston calipers with 310mm discs
Rear Brake	Single 220mm disc
Front Tire	120/70ZR-17
Rear Tire	180/55ZR-17
Rake	23.5 degrees
Wheelbase	53.9 inches
Seat Height	32.3 inches
Curb Weight	410 pounds
Fuel Capacity	4.8 gallons
Induction	PGM-DSFI
Transmission	6-speed
Front Suspension	41mm inverted with spring preload, rebound and compression damping adjustability; 4.3 inches travel
