43
SERVICING YOUR GENERATOR
AIR CLEANER SERVICE
1.Loosen the maintenance cover
screw and remove the
maintenance cover.
2.Loosen the air cleaner cover
screw, and remove the air
cleaner cover.
3.Remove the main and outer
filters from the air cleaner
case.
4.Check the main and outer filters to be sure they are clean and in
good condition. If the main and outer filters are dirty, clean them as
described on page
45. Replace the main and outer filters if they are
damaged.
MAINTENANCE
COVER SCREW
MAINTENANCE
COVER
MAIN FILTERMAIN FILTER
AIR CLEANER
COVER SCREW
OUTER FILTER
AIR CLEANER COVER
AIR CLEANER CASE
