Honda EB2000i - Specifications

64
TECHNICAL INFORMATION
Specifications
Dimensions
Engine
Generator
Tuneup Specifications
Specifications are subject to change without notice.
Model EB2000i
Description code EAET
Length 20.2 in (512 mm)
Width 11.4 in (290 mm)
Height 16.7 in (425 mm)
Dry mass [weight] 45.6 lbs (20.7 kg)
Model GX100
Engine type 4-stroke, overhead camshaft, single cylinder
Displacement
[Bore×Stroke]
6.01 cu-in (98.5 cm
3
)
[2.20×1.57 in (56.0×40.0 mm)]
Compression ratio 8.5:1
Engine speed 4,300–5,000 rpm
(with Eco-Throttle switch OFF)
Cooling system Forced air
Ignition system Full transistor
Engine oil capacity 13 oz (0.40 L)
Fuel tank capacity 0.95 US gal (3.6 L)
Spark plug CR5HSB (NGK)
Model EB2000i
Type A type
AC output
Rated Voltage 120 V
Rated Frequency 60 Hz
Rated Current 13.3 A
Rated Output 1.6 kVA
Maximum Output 2.0 kVA
ITEM SPECIFICATION MAINTENANCE
Spark plug gap 0.024 – 0.028 in (0.6 – 0.7 mm) Refer to page 46.
Valve clearance
(cold)
IN: 0.15±0.04 mm
EX: 0.20±0.04 mm
See your authorized
Honda dealer.
Other specifications No other adjustments needed.
