Honda EB2200i User Manual

TECHNICAL INFORMATION
73
SPECIFICATIONS
Dimensions
Engine
Generator
Model EB2200iT
Description code EAJT
Length 20.0 in (509 mm)
Width 11.4 in (290 mm)
Height 16.7 in (425 mm)
Dry mass [weight] 47.4 lbs (21.5 kg)
Model GXR120T
Engine type 4-stroke, overhead camshaft, single cylinder
Displacement
[Bore × Stroke]
7.38 cu-in (121 cm
3
)
[2.36 × 1.69 in (60.0 × 43.0 mm)]
Compression ratio 8.5:1
Engine speed 4,000 – 4,500 rpm
(with Eco Throttle switch OFF)
Cooling system Forced air
Ignition system Full transistor
Engine oil capacity 14 oz (0.44 L)
Fuel tank capacity 0.95 US gal (3.6 L)
Spark plug CR5HSB (NGK)
Model EB2200iT
Type AG type
AC output Rated Voltage 120 V
Rated Frequency 60 Hz
Rated Current 15 A
Rated Output 1.8 kVA
Maximum Output 2.2 kVA
31Z448100.book 73 ページ ２０２０年２月１７日 月曜日 午前１１時５１分

Honda EB2200i Specifications

General

Model	EB2200i
Category	Inverter
Displacement	121cc
Receptacles	20A 125V Duplex
Starting System	Recoil
Fuel Tank Capacity	0.95 gal
Dimensions (L x W x H)	20.0" x 11.4" x 16.7"
Engine	Honda GXR120
AC Output	120V 2200W max. (18.3A) / 1800W rated (15A)
Run Time per Tankful	3.2hr @ rated load, 8.1 hrs @ 1/4 load
Noise Level	53 dB(A) @ 1/4 load
