GENERAL DESCRIPTION
ECMT7000, GV type
[1] Fuel filler cap [9] Engine oil drain plug
[2] Fuel tank [10] Muffler
[3] Fuel level indicator [11] Air cleaner
[4] Recoil starter grip [12] Thermal circuit breakers
[5] Fuel shut-off valve [13] Receptacle 230 V/16 A (blue) F, GV types
[6] Choke lever [14] Receptacle 230 V/16 A (blue) F, GV types
[7] Spark plug cap [15] Receptacle 400 V/16 A (red) F, GV types
[8] Oil filler cap / Dipstick [16] Hour meter
[8’] Oil filler cap [17] Engine switch
[18] Transport kit
[13]
[14]
[15]
[5]
[4]
[6]
[11]
[1]
[3]
[2]
[12]
[16][17]
[18]
[9]
[8]
[10]
[7]
[8’]
[13]
[14]
[12]
[14]
[15]
[12]
[16]
[17]
F Type
