Honda ECMT7000 - General Description

7
GENERAL DESCRIPTION
ECM2800 GV, VW types
[1] Fuel filler cap [9] Engine oil drain plug
[2] Fuel tank [10] Muffler
[3] Fuel level indicator [11] Air cleaner
[4] Recoil starter grip [12] Thermal circuit breakers
[5] Fuel shut-off valve [13] Receptacles 230V/16A (blue) F, GV, B types
[6] Choke lever [13’] Receptacle 115V/16A (yellow) B type
[7] Spark plug cap [14] Engine switch
[8] Oil filler cap / Dipstick [15] Voltage selector switch 115/230 V, B type
[8’] Oil filler cap (choice of [8] or [8’]
as required)
[11]
[6]
[5]
[4]
[13]
[12]
[13]
[12]
[7]
[8]
[3]
[2]
[1]
[8’]
[9]
[14]
[10]
F Type
[12]
[15]
[13’]
[13]
[12]
B Type
