Inspecting the Rear Brake Shoe
Wear
The rear brake is equipped with a brake wear
indicator.
When the brake is applied, an arrow attached
to the brake arm moves toward a reference
mark on the brake panel. If the arrow aligns
with the reference mark on full application of
the brake, the brake shoes must be replaced.
See your authorised dealer for this service.
When brake service is necessary, see your
authorised dealer. Use only Honda Genuine
Parts or their equivalent.
Brakes u Inspecting the Rear Brake Shoe Wear
Maintenance
69
Reference mark
Arrow
Brake arm
