Throttle
Checking the Throttle
With the power switch is in the (Off)
position, check that the throttle rotates
smoothly from fully closed to fully open in all
steering positions and throttle freeplay is
correct. If the throttle does not move
smoothly or close automatically, or if the
cable is damaged, have the vehicle inspected
by your authorised dealer.
Freeplay at the throttle grip flange:
2 - 6 mm (0.1 - 0.2 in)
Maintenance
71
Freeplay
Flange
