40
ENGINE OIL CHANGE
Oil capacity:
OIL FILLER NECK
UPPER LIMIT
Drain the used oil while the engine is warm. Warm oil drains quickly
and completely.
Place a suitable container next to the engine to catch the used oil.
Turn the engine switch and vent lever to the OFF position to reduce
the possibility of fuel leakage.
Loosen the cover screw and remove the left-side maintenance cover
(see page 27 ).
Remove the oil filler cap/dipstick, and drain the oil into the container
by tipping the engine toward the oil filler neck.
With the engine in a level position, fill to the upper limit of the oil
filler neck with the recommended oil (see page ).
Reinstall the oil filler cap/dipstick securely.
Reinstall the left-side maintenance cover and tighten the cover
screw securely.
1.
2.
3.
4.
5.
6.
7.
27
0.26 US qt (0.25 )
05/06/20 14:32:16 31ZT3604_041
