Honda Goldwing F6B User Manual

Functional Check:
Perform the following maintenance in accordance with the maintenance
schedule.
If the side stand system does not operate as described, see your dealer for
service.
Check the spring for damage or loss of tension and the side stand assembly
for freedom of movement.
Check the side stand ignition cut-off system:
Sit astride the motorcycle; put the side stand up and the transmission in
neutral.
Start the engine and with the clutch lever pulled in, shift the transmission
into gear.
Lower the side stand. The engine should stop as you put the side stand
down.
Refer to the Safety Precautions on page .
1.
2.
3.
Spring
131
SIDE STAND
153
12/12/06 16:29:17 32MJG600_163

Honda Goldwing F6B Specifications

General

Engine Type	1832cc liquid-cooled horizontally opposed six-cylinder
Bore and Stroke	74mm x 71mm
Compression Ratio	9.8:1
Fuel System	Programmed Fuel Injection (PGM-FI)
Ignition	Computer-controlled digital with three-dimensional mapping
Final Drive	Shaft
Front Tire	130/70R-18
Rear Tire	180/60R-16
Wheelbase	66.5 inches
Seat Height	28.5 inches
Fuel Capacity	6.6 gallons
Curb Weight	842 pounds
Transmission	Five-speed including Overdrive
Front Suspension	45mm fork; 4.8 inches travel
Rear Suspension	Pro-Link single shock with hydraulic spring preload adjustment; 4.1 inches travel
Front Brakes	Dual 296mm discs with CBS three-piston calipers
Rear Brakes	Single 316mm disc with CBS three-piston caliper
