Honda GX35T User Manual

2011.10.10 E
33
2
E-40
OTHER PARTS
Ref.
No.
Part No. Description
Reqd. QTY
Parts catalogue code
GX
35
T
Serial No.
1 22100-VK4-M00 OUTER COMP., CLUTCH ••••••••• 1 -------- -------- SAMS
2 22260-VK4-M01 HOUSING ASSY., CLUTCH ••••••• 1 -------- -------- SAMS
3 22261-VK4-003 HOUSING, CLUTCH ••••••••••••• 1 -------- -------- SAMS
4 36100-ZE1-015 SWITCH ASSY., ENGINE STOP ••• 1 -------- -------- SAMS
5 90101-VK4-003 BOLT, SOCKET, 6X20 •••••••••• 1 -------- -------- SAMS
6 90102-VK4-000 BOLT, FLANGE SOCKET, 6X20 ••• 4 -------- -------- SAMS
7 90103-VK4-003 BOLT, SOCKET, 5X20 •••••••••• 3 -------- -------- SAMS
8 90401-VK4-003 WASHER, 5MM ••••••••••••••••• 3 -------- -------- SAMS
9 93403-06028-08 BOLT-WASHER, 6X28 ••••••••••• 1 -------- -------- SAMS
10 93892-05010-07 SCREW-WASHER, 5X10 •••••••••• 1 -------- -------- SAMS
11 93893-05010-08 SCREW-WASHER, 5X10 •••••••••• 1 -------- -------- SAMS
12 94510-15000 CIRCLIP, EXTERNAL, 15MM ••••• 1 -------- -------- SAMS
13 94510-30000 CIRCLIP, EXTERNAL, 30MM ••••• 1 -------- -------- SAMS
14 94520-35000 CIRCLIP, INTERNAL, 35MM ••••• 1 -------- -------- SAMS
15 96130-62020-10 BEARING, RADIAL BALL, 6202 •• 1 -------- -------- SAMS
Ref.
No.
L.O.N.
(Relative ref. Number)
Description
F.R.T.
1 2121C0 OUTER, CLUTCH •••••••••••••••• 0.2
2 2121E8 HOUSING ASSEMBLY, CLUTCH ••••• 0.1
3 2121B6 HOUSING, CLUTCH •••••••••••••• 0.3
15 2121E7 BEARING, CLUTCH OUTER •••••••• 0.3
D 1
