uuAdjusting the SeatsuFront Seats
212
■ Adjusting the front manual seat
■
Adjusting the Seat Positions
1Adjusting the front manual seat
Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.
a Horizontal Position Adjustment
Pull up on the bar to move the seat, then release the bar.
b Seat-back Angle Adjustment
Pull up the lever to change the angle.
c Height Adjustment (Driver side only)
Pull up or push down the lever to raise or lower the seat.
21 JAZZ HYBRID SSS-32TZA6000.book 212 ページ ２０２０年１月２９日 水曜日 午前１０時３２分
