uuReplacing Light BulbsuBrake/Taillight and Rear Turn Signal Light Bulbs
Maintenance
Brake/Taillight and Rear Turn Signal Light Bulbs
When replacing, use the following bulbs.
1. Remove the cover.
2. Use a Phillips-head screwdriver to remove
the bolts.
3. Pull the light assembly out of the rear pillar.
4. Turn the socket anticlockwise and remove
it. Remove the old bulb.
5. Insert a new bulb.
Brake Light: LED
Taillight: LED
Rear Turn Signal Light: 21 W (Amber)
1Brake/Taillight and Rear Turn Signal Light Bulbs
Brake/taillights are LED type. Have an authorised
Honda dealer inspect and replace the light assembly.
a Cover
b Bolt
a Bulb
b Socket
