581
uuReplacing Light BulbsuBrake Light and Turn Signal Light Bulbs
Brake Light and Turn Signal Light Bulbs
When replacing, use the following bulbs.
1. Use a Phillip-head screwdriver to remove
the bolts.
2. Pull the light assembly out of the rear pillar.
3. Turn the socket counterclockwise and
remove it. Remove the old bulb.
4. Insert a new bulb and turn clockwise.
5. Slide the light assembly onto the guide on
the body.
6. Align the pins with the body grommets,
then push in until they fully seat.
Taillight and Rear Side Marker Lights
Taillight and rear side marker lights are LED type. Have an authorized Honda dealer
inspect and replace the light assembly.
Brake Light: LED
Rear Turn Signal Light: 21 W
1Brake Light and Turn Signal Light Bulbs
Brake lights are LED type. Have an authorized Honda
dealer inspect and replace the light assembly.
16 PILOT-31TG76000.book 581 ページ ２０１６年１０月１９日 水曜日 午後５時４分
To Next Page
