Specifications
■ Main Components
Overall length 86.2 in (2,190 mm)
Overall width 32.3 in (820 mm)
Overall height 42.9 in (1,090 mm)
Wheelbase 58.7 in (1,490 mm)
Minimum ground
clearance
5.9 in (150 mm)
Caster angle 28° 0’
Trail 4.3 in (110 mm)
Curb weight
CMX300
49 STATE 364 lb (165 kg)
50 STATE (meets
California)
366 lb (166 kg)
Canada model 364 lb (165 kg)
CMX300A
50 STATE (meets
California)
370 lb (168 kg)
Canada model 368 lb (167 kg)
Maximum weight
capacity
Model not equipped
with Optional
Passenger Seat Kit
*1
346 lb (157 kg)
Model equipped with
Optional Passenger
Seat Kit
*2
346 lb (157 kg)
*1 : Including rider, all luggage, and accessories
*2 : Including rider, passenger, all luggage, and accessories
Passenger
capacity
Model not equipped
with Optional
Passenger Seat Kit
Rider only (no
passenger)
Model equipped with
Optional Passenger
Seat Kit
Rider and 1
passenger
Minimum
turning radius
9.2 ft (2.8 m)
Displacement 17.4 cu-in (286 cm
3
)
Bore x stroke 2.99 x 2.48 in (76.0 x 63.0 mm)
Compression
ratio
10.7 : 1
Fuel
Unleaded gasoline
Recommended: 86 PON or higher
Tank capacity 2.96 US gal (11.2 L)
Battery
YTZ8V
12 V-7 Ah (10 HR)
Gear ratio
1st 3.416
2nd 2.250
3rd 1.650
4th 1.350
5th 1.166
6th 1.038
Reduction ratio
(primary / final)
2.807 / 2.571
20161124110921_31K87A000_enu_BOOK Page 136 Thursday, November 24 2016 11:13:27 JST
Specifications
133

Honda Rebel 2017 Specifications

General

Compression Ratio	10.7:1
Transmission	6-speed
Final Drive	O-ring-sealed chain
Front Suspension	41mm fork; 4.8 inches travel
Front Brake	Single 296mm disc with two-piston caliper
Front Tire	130/90-16
Rear Tire	150/80-16
Trail	110mm (4.3 inches)
Wheelbase	58.7 inches
Seat Height	27.2 inches
Curb Weight	408 pounds
Bore x Stroke	67mm x 66.8mm
Induction	PGM-FI
Rear Suspension	Dual shocks with 3.8 inches travel
Rear Brake	240mm disc
Rake (Caster Angle)	28 degrees
Valve Train	DOHC; four valves per cylinder
Engine Type	471cc liquid-cooled parallel-twin
