Honda Rebel 2017 User Manual

Side Stand
Checking the Side Stand
1. Check that the side stand operates
smoothly. If the side stand is stiff or
squeaky, clean the pivot area and
lubricate the pivot bolt with clean grease.
2. Check the spring for damage or loss of
tension.
3. Sit on the motorcycle, shift the
transmission to Neutral, and raise the side
stand.
4. Start the engine, pull the clutch lever in,
and shift the transmission into gear.
5. Lower the side stand all the way. The
engine should stop as you lower the side
stand. If the engine doesn't stop, have
your motorcycle inspected by your dealer.
20161124110921_31K87A000_enu_BOOK Page 83 Thursday, November 24 2016 11:13:27 JST
Maintenance
80
Side stand
spring

Honda Rebel 2017 Specifications

General

Compression Ratio	10.7:1
Transmission	6-speed
Final Drive	O-ring-sealed chain
Front Suspension	41mm fork; 4.8 inches travel
Front Brake	Single 296mm disc with two-piston caliper
Front Tire	130/90-16
Rear Tire	150/80-16
Trail	110mm (4.3 inches)
Wheelbase	58.7 inches
Seat Height	27.2 inches
Curb Weight	408 pounds
Bore x Stroke	67mm x 66.8mm
Induction	PGM-FI
Rear Suspension	Dual shocks with 3.8 inches travel
Rear Brake	240mm disc
Rake (Caster Angle)	28 degrees
Valve Train	DOHC; four valves per cylinder
Engine Type	471cc liquid-cooled parallel-twin
