Honda SH300 2010 User Manual

5-1
5
5. LUBRICATION SYSTEM
LUBRICATION SYSTEM DIAGRAM ·········· 5-2
SERVICE INFORMATION ··························· 5-3
TROUBLESHOOTING ································· 5-4
OIL PRESSURE CHECK ······························ 5-5
OIL STRAINER ············································ 5-6
OIL PRESSURE RELIEF VALVE ················· 5-7
OIL PUMP ··················································· 5-8

Honda SH300 2010 Specifications

General

Displacement	279cc
Bore x Stroke	72 mm x 68.5 mm
Compression Ratio	10.5:1
Max Torque	26.5 Nm at 6, 000 rpm
Fuel System	PGM-FI electronic fuel injection
Ignition	Digital transistorized with electronic advance
Front Suspension	Telescopic fork
Front Tire	110/70-16
Rear Tire	130/70-16
Curb Weight	169 kg
Height	1, 195 mm
Engine Type	Liquid-cooled, 4-stroke, single-cylinder
Transmission	V-Matic
Front Brake	Single 256 mm disc
Rear Brake	Single 240 mm disc
Rear Suspension	Dual shock absorbers
