4.
Reassemble the brake stopper arm.
Tighten the stopper arm nut.
Torque: 16 lbf·ft (22 N·m, 2.2 kgf·m)
5.
Connect the brake rod to the brake arm.
6.
Adjust the rear brake pedal freeplay.
2 P. 68
7.
Tighten the rear axle nut.
Torque: 65 lbf·ft (88 N·m, 9.0 kgf·m)
8.
Tighten the axle holding bolt.
Torque: 20 lbf·ft (27 N·m, 2.8 kgf·m)
9.
After installing the wheel, apply the brake
pedal several times, then check if the
wheel rotates freely. Recheck the wheel if
the brake drags or if the wheel does not
rotate freely.
A used cotter pin may not effectively secure a
fastener. Always replace a used cotter pin
with a new one.
Tire Puncture u Removing Wheels
Troubleshooting
91
Continued
To Next Page
