Brake Light/Taillight Bulb
1. Remove the taillight lens by removing the
screws.
2. Slightly press the bulb in and turn it
counterclockwise.
3. Install a new bulb and parts in the reverse
order of removal.
u
After putting back the lens packing in
place, install the taillight lens.
#
Front/Rear Turn Signal Bulb
1. Remove the turn signal lens and lens
packing by removing the screw.
2. Slightly press the bulb and turn it
counterclockwise.
3. Install a new bulb and parts in the reverse
order of removal.
u
After putting back the lens packing in
place, install the turn signal lens.
Electrical Trouble u Burned-out Light Bulb
Troubleshooting
95
Continued
Taillight lens
ScrewsBulb
Turn signal
lens
Lens packing
Screw Bulb
