Specifications
107
Specifications
■ Bulbs
■ Fuses
■ Torque Specifications
Drive chain slack 20 to 30 mm (0.8 to 1.2 in)
Standard drive
chain
KMC420JB
DID420AD2
RK420EL
No. of links 104
Standard
sprocket size
Drive sprocket 14T
Driven sprocket 37T
Headlight 12 V-35/35 W
Brakelight/Taillight 12 V-21/5 W
Front turn signal light 12 V-10 W x 2
Rear turn signal light 12 V-10 W x 2
Position light 12 V-5 W
License plate light 12 V-5 W
Main fuse 10 A
Other fuse 7.5 A
Engine oil drain bolt 24 N·m (2.4 kgf·m, 18 lbf·ft)
Front wheel axle nut 59 N·m (6.0 kgf·m, 44 lbf·ft)
Rear wheel axle nut 59 N·m (6.0 kgf·m, 44 lbf·ft)
Rear brake stopper arm nut 22 N·m (2.2 kgf·m, 16 lbf·ft)
