Honda WAVE ALPHA - Headlight Case

Removing & Installing Body Components u Headlight Case
51
continued
Maintenance
Headlight Case
#
Removal
1. Pull up the rubber dust covers.
2. Loosen the lock nuts by turning clockwise.
3. Loosen the rearview mirrors and remove
them by turning them clockwise.
4. Loosen the mirror adapters by turning
counterclockwise and remove them.
Rubber dust covers
Lock nut
Lock
nut
Rearview mirrors
Mirror
adapter
Mirror
adapter
