Electrical Trouble u Blown Fuse
93
Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.” 2 P. 40
#
Fuse Box Fuses
1.
Open the seat. 2 P. 30
2.
Remove the battery cover. 2 P. 49
3.
Open the fuse box covers.
4.
Pull out the fuses one by one to check for a
blown fuse. Always replace a blown fuse
with a spare fuse of the same rating.
u The spare fuses are located on reverse
side of the battery cover.
5.
Close the fuse box covers.
6.
Install the battery cover.
7.
Close the seat.
If a fuse fails repeatedly, you likely have an electrical
problem. Have your vehicle inspected by your dealer.
Spare fuses
Sub fuse
Main fuse
Fuse boxes
20 AFS110MD MCS (MA)-32K71A200.book Page 93 Wednesday, October 16, 2019 5:41 PM
