14
Operation Guide
Parts Location
AFS110MD
Engine oil drain bolt (P57)
Battery
(P49)
Fuse box (P93)
Helmet holder (P30)
Throttle grip (P73)
Engine oil fill cap/dipstick
(P56)
Spark plug (P54)
Kickstarter (P24)
Front brake lever (P61)
Main pipe cover (P53)
Rear brake pedal (P63)
Brakelight switch (P66)
