Tyre Puncture u Removing Wheels
80
Removing Wheels
Follow these procedures if you need to
remove a wheel in order to repair a puncture.
#
Front Wheel
Removal
1.
Place your vehicle on its centre stand on a
firm, level surface.
2.
Support your vehicle securely and raise the
front wheel off the ground using a
maintenance stand or a hoist.
3.
Remove the speedometer cable by
pushing the tab.
4.
Remove the front brake adjusting nut and
disconnect the front brake cable from the
brake arm.
5.
Remove the front axle nut.
6.
Remove the front axle shaft, front wheel,
and side collar.
Front brake cable
Tab
Brake arm
Front brake
adjusting nut
cable
Front axle shaft
20 AFS110MD MCS (MA)-32K71A200.book Page 80 Wednesday, October 16, 2019 5:41 PM
