Electrical Trouble u Burned-out Light Bulb
91
continued
#
Rear Turn Signal Bulb
1.
Remove the turn signal lens by removing
the screw.
2.
Turn the socket counterclockwise and pull
it out.
3.
Pull out the bulb without turning it.
4.
Install a new bulb and parts in the reverse
order of removal.
u Install the socket by turning it clockwise.
Make sure that the “
5” marks on the
socket and turn signal housing are
aligned.
u Use only the amber bulb.
Socket
Bulb
“
5”marks
Turn signal lens
Screw
