5.
Remove the front top cover. 2 P. 50
6.
Remove the screws A, screws B and bolt.
7.
Remove the headlight case and
disconnect the connector.
#
Installation
Install the parts in the reverse order of
removal.
u To install the rearview mirrors.
20181207113539_32KVMC000_eng_BOOK Page 55 Friday, December 07 2018 11:40:26 JST
Removing & Installing Body Components u Headlight Case
Maintenance
52
Screws A
Headlight case
Bolt
Connector
Screws B
To Next Page
