4.
Move the drive chain up and down with
your finger.
Drive chain slack:
35 - 45 mm (1.4 - 1.8 in)
u Do not ride your motorcycle if the
slack exceeds 50 mm (2.0 in).
5.
Rotate the rear wheel and check that the
chain moves smoothly.
6.
Remove the chain covers by removing the
bolts.
7.
Inspect the sprockets. 2 P. 41
8.
Clean and lubricate the drive chain.
2 P. 41
9.
Install the parts in the reverse order of
removal.
10.
Tighten the bolts.
Torque: 7 N·m (0.7 kgf·m, 5.2 lbf·ft)
20181207113539_32KVMC000_eng_BOOK Page 71 Friday, December 07 2018 11:40:26 JST
Drive Chain u Inspecting the Drive Chain Slack
Maintenance
68
Bolts Chain covers
