Adjust the drive chain slack at a point
midway between the drive sprocket and
the driven sprocket.
Check the drive chain slack. 2 P. 67
7.
Check rear axle alignment by making sure
the end of the drive chain adjuster aligns
with the scale graduations on both sides
of the swingarm.
Both marks should correspond. If the axle
is misaligned, turn the right or left
adjusting nut until the marks are aligned
and recheck drive chain slack.
8.
Tighten the rear axle nut.
Torque: 59 N·m (6.0 kgf·m, 44 lbf·ft)
9.
Tighten the drive chain adjusting nuts
lightly, then hold the adjusting nuts and
tighten the lock nuts.
10.
Recheck drive chain slack.
11.
Rear brake pedal freeplay is affected
when repositioning the rear wheel to
adjust drive chain slack. Check rear brake
pedal freeplay and adjust as necessary.
2 P. 59
12.
Reinstall the inspection hole cap.
If a torque wrench was not used for
installation, see your dealer as soon as
possible to verify proper assembly.
Improper assembly may lead to loss of
braking capacity.
20181207113539_32KVMC000_eng_BOOK Page 73 Friday, December 07 2018 11:40:26 JST
Drive Chain u Adjusting the Drive Chain Slack
Maintenance
70
