GENERAL INFORMATION
TORQUE VALUES
STANDARD TORQUE VALUES
ENGINE & FRAME TORQUE VALUES
FRAME/BODY PANELS/EXHAUST SYSTEM
MAINTENANCE
IGNITION SYSTEM
ELECTRIC STARTER (XR125LEK)
FASTENER TYPE
TORQUE
FASTENER TYPE
TORQUE
N·m (kgf·m, lbf·ft) N·m (kgf·m, lbf·ft)
5 mm hex bolt and nut 5.2 (0.5, 3.8) 5 mm screw 4.2 (0.4, 3.1)
6 mm hex bolt and nut 10 (1.0, 7) 6 mm screw 9.0 (0.9, 6.6)
(Include SH flange bolt) 6 mm flange bolt
(Include NSHF) and nut
12 (1.2, 9)
8 mm hex bolt and nut 22 (2.2, 16)
10 mm hex bolt and nut 34 (3.5, 25) 8 mm flange bolt and nut 27 (2.8, 20)
12 mm hex bolt and nut 54 (5.5, 40) 10 mm flange bolt and nut 39 (4.0, 29)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Exhaust pipe joint nut 2 8 18 (1.8, 13)
Exhaust pipe protector bolt 2 6 14 (1.4, 10)
Muffler rear mounting nut 2 8 26 (2.7, 19)
Muffler front mounting bolt 2 8 26 (2.7, 19)
Muffler band bolt 1 8 20 (2.0, 15)
Exhaust pipe stud bolt 2 8 11 (1.1, 8) See page 2-6
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Air cleaner case cover screw 4 5 1.1 (0.1, 0.8)
Air cleaner element screw 4 5 1.1 (0.1, 0.8)
Spark plug 1 10 16 (1.6, 12)
Valve adjusting lock nut 2 6 14 (1.4, 10) Apply engine oil to the threads and
seating surface.
Crankshaft hole cap 1 32 15 (1.5, 11) Apply grease to the threads.
Timing hole cap 1 14 10 (1.0, 7)
Engine oil drain bolt 1 12 30 (3.1, 22)
Oil filter rotor cover screw 3 5 4.0 (0.4, 3.0)
Rear axle nut 1 16 93 (9.5, 69) U-nut
Drive sprocket fixing plate bolt 2 6 12 (1.2, 9)
Driven sprocket nut 6 10 32 (3.3, 24) U-nut
Sidestand pivot bolt 1 10 10 (1.0, 7)
Sidestand pivot nut 1 10 39 (4.0, 29) U-nut
Front spoke 36 BC3.2 3.7 (0.4, 2.7)
Rear spoke 36 BC3.2 3.7 (0.4, 2.7)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Timing hole cap 1 14 10 (1.0, 7)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Starter motor case bolt 2 6 10 (1.0, 7)
