Standard Cable Pinouts
Serial Output
10 Pin RJ41 Modular Plug connects to the base
1 Cable shield 2Cable select 3 Supply ground 4 Transmit data 5 Receive data - serial data to scanner 6CTS 7+5V power 8RTS 9 10
Note: Pin assignments are not compatible with Honeywell legacy products.
Use of a cable with improper pin assignments may lead to damage to the unit.
Use of any cables not provided by the manufacturer may result in damage not
covered by your warranty.
