Honeywell 1900GSR-2USB User Manual

12 - 7
Standard Cable Pinouts
USB
10 Pin Modular Plug connects to the base
1 Cable shield 2 Cable select 3 Supply ground 4 5 6 7 +5V power 8 9Data + 10 Data -
Note: Pin assignments are not compatible with Honeywell legacy products.
Use of a cable with improper pin assignments may lead to damage to the unit.
Use of any cables not provided by the manufacturer may result in damage not
covered by your warranty.
