STEP 3. MOUNT THERMOSTAT WALLPLATE
WIRES
THROUGH WALL
WALL
MOUNTING
HOLES
M15044
MOUNTING
SCREWS
WALL
ANCHORS
(2)
❑ Position wallplate on wall. Level the
wallplate for appearance if desired. Use a
pencil to mark the two mounting holes that
best fit the application.
❑ Remove wallplate from wall, and drill
3/16 inch holes in wall (if drywall) as
marked. For firmer material such as
plaster or wood, drill 7/32 inch holes.
Gently tap anchors (provided) into drilled
holes until flush with the wall.
❑ Reposition wallplate over holes, pulling
wires through wiring opening. Loosely
insert two mounting screws into holes.
❑ Level for appearance only; thermostat
functions properly even when not level.
Tighten mounting screws.

Honeywell 36 Specifications

General

Type	Non-Programmable
Programmable	No
Backlit Display	No
Hold Function	Yes
Filter Change Alert	No
Battery Indicator	Yes
Power Source	Battery
Compatibility	Single Stage Heating and Cooling Systems
