Honeywell 7800 SERIES

7800 SERIESS7800A2142 4Line LCD Keyboard Display Module
63 320011007
Fault
Code
(Reg
40001)
Fault Message
(NOTE: FAULT n: is not in
the Fault and Strings Code)
Fault
String
Code
(Table
21)
163 FAULT 32a: AUX LIMIT #1EA 17
164
FAULT 30s: OTHER INTERLOCK-
SEA
74
165
FAULT 30r: AUX INTERLOCK
#5EA
16
166
FAULT 30q: AUX INTERLOCK
#4EA
15
167 FAULT 30p: AIRFLOW SWITCHEA 13
168
FAULT 30o: LOW GAS PRESSU-
REEA
59
169
FAULT 30n: HIGH GAS PRESSU-
REEA
41
170 FAULT 30m: ATOMIZING SWEA 14
171 FAULT 30k: LOW OIL TEMPEA 62
172 FAULT 30j: HIGH OIL TEMPEA 44
173
FAULT 30i: LOW OIL PRESSU-
REEA
61
174
FAULT 30h: HIGH OIL PRESSU-
REEA
43
175
FAULT 30g: BOTH FUELS SE-
LECTEA
21
176 FAULT 30f: FUEL SELECT OFFEA 38
177 FAULT 30e: AUX LIMIT #3EA 19
178 FAULT 30d: HIGH LIMITEA 42
179 FAULT 30c: LWCOEA 63
180 FAULT 30b: AUX LIMIT #2EA 18
181 FAULT 30a: AUX LIMIT #1EA 17
182
FAULT 29s: OTHER INTERLOCK-
SEA
74
183
FAULT 29r: AUX INTERLOCK
#5EA
16
184
FAULT 29q: AUX INTERLOCK
#4EA
15
185 FAULT 29p: AIRFLOW SWITCHEA 13
186
FAULT 29o: LOW GAS PRESSU-
REEA
59
187
FAULT 29n: HIGH GAS PRESSU-
REEA
41
188 FAULT 29m: ATOMIZING SWEA 14
189 FAULT 29k: LOW OIL TEMPEA 62
190 FAULT 29j: HIGH OIL TEMPEA 44
191
FAULT 29i LOW OIL PRESSU-
REEA
61
192
FAULT 29h: HIGH OIL PRESSU-
REEA
43
193
FAULT 29g: BOTH FUELS SE-
LECTEA
21
194 FAULT 29f: FUEL SELECT OFFEA 38
195 FAULT 29e: AUX LIMIT #3EA 19
196 FAULT 29d: HIGH LIMITEA 42
Fault
Code
(Reg
40001)
Fault Message
(NOTE: FAULT n: is not in
the Fault and Strings Code)
Fault
String
Code
(Table
21)
197 FAULT 29c: LWCOEA 63
198 FAULT 29b: AUX LIMIT #2EA 18
199 FAULT 29a: AUX LIMIT #1EA 17
200
FAULT 23s: OTHER INTERLOCK-
SEA
74
201
FAULT 23r: AUX INTERLOCK
#5EA
16
202
FAULT 23q: AUX INTERLOCK
#4EA
15
203 FAULT 23p: AIRFLOW SWITCHEA 13
204
FAULT 23o: LOW GAS PRESSU-
REEA
59
205
FAULT 23n: HIGH GAS PRESSU-
REEA
41
206 FAULT 23m: ATOMIZING SWEA 14
207 FAULT 23k: LOW OIL TEMPEA 62
208 FAULT 23j: HIGH OIL TEMPEA 44
209
FAULT 23i LOW OIL PRESSU-
REEA
61
210
FAULT 23h: HIGH OIL PRESSU-
REEA
43
211
FAULT 23g: BOTH FUELS SE-
LECTEA
21
212 FAULT 23f: FUEL SELECT OFFEA 38
213 FAULT 23e: AUX LIMIT #3EA 19
214 FAULT 23d: HIGH LIMITEA 42
215 FAULT 23c: LWCOEA 63
216 FAULT 23b: AUX LIMIT #2EA 18
217 FAULT 23a: AUX LIMIT #1EA 17
218
FAULT 22s: OTHER INTERLOCK-
SEA
74
219
FAULT 22r: AUX INTERLOCK
#5EA
16
220
FAULT 22q: AUX INTERLOCK
#4EA
15
221 FAULT 22p: AIRFLOW SWITCHEA 13
222
FAULT 22o: LOW GAS PRESSU-
REEA
59
223
FAULT 22n: HIGH GAS PRESSU-
REEA
41
224 FAULT 22m: ATOMIZING SWEA 14
225 FAULT 22k: LOW OIL TEMPEA 62
226 FAULT 22j: HIGH OIL TEMPEA 44
227
FAULT 22i: LOW OIL PRESSU-
REEA
61
228
FAULT 22h: HIGH OIL PRESSU-
REEA
43
229
FAULT 22g: BOTH FUELS SE-
LECTEA
21
230 FAULT 22f: FUEL SELECT OFFEA 38
