Radio module or cellular communication active or Optical communication is active.
The optical communication and cellular communication are mutually exclusive; only one
communication is allowed at any time.
Radio module or cellular communication inactive and optical communicant is also inactive.
Pairing is successful with cellular communication or Optical communication.
Rf Inactive: this holds least priority. This will appear if no other communication icon is present
& RF is inactive (need to add to top).
Index Time Sync Failure: This icon appears if time sync of index fails.
Metrology Logbook Full: This icon appears if metrology logbook is full or >90% of if there is a
memory error.
Low battery. This symbol is only displayed when battery power is low.
Temperature alert: This icon appears when current temperature crosses max limit of
Temperature Adjust OBIS.
Pressure alert: This icon appears when current pressure crosses max limit of Pressure Adjust
OBIS.
Pressure above threshold: This appears when current pressures cross the high close
threshold of the VEM pressure threshold.
Pressure above normal: This appears when current pressures cross the high warning
threshold of the VEM pressure threshold.
