10 PIN SLOTS. Located on 24-hour dial at
10-minute intervals for program pin
insertion.
11 MERCURY BULB AND BIMETAL ELEMENT
(2). Provide automatic temperature control
by switching the heating or cooling system
on and off.
12 WALLPLATE. Provides mounting base
and wiring connections for heating or
cooling thermostat without system or fan
switching.
