Honeywell BENDIX/KING KCS55 - Kg 102;102 A Directional Gyro; Kmt 112 Magnetic Azimuth Transmitter; Ka 51;51 A;51 B Slaving Accessory; KI 525 Version Chart

BENDIX/KING KCS 55/55A
Page 1-8
©Honeywell International Inc. Do not print without express permission of Honeywell Rev 11, Apr/2007
Table 1-1 KI 525A Version Chart
Table 1-2 KI 525 Version Chart
1.4.2 KG 102/102A DIRECTIONAL GYRO
The KG 102/102A Directional Gyro is a remote mounted unit which, in conjunction with the KMT
112 Magnetic Azimuth Transmitter, provides a gyro stabilized magnetic heading to the KI 525/
525A Indicator. In addition to the slaving circuitry the KG 102/102A contains an internal power
supply which provides gyro rotor power, excitation voltages for the Magnetic Azimuth Transmitter,
and positive and negative D.C. voltages for the Pictorial Navigation Indicator and the Slaving Ac-
cessory.
PN 060-0011-00 is the only version available for the KG 102. The KG 102A is available in a stan-
dard version (PN 060-0015-00), a version with RFI filter (PN 060-0015-01), and a version with RFI
filter and tumble detection (PN 060-0015-02).
1.4.3 KMT 112 MAGNETIC AZIMUTH TRANSMITTER
The KMT 112 (PN 071-1052-00) senses the direction of the earth’s magnetic field and transmits
this information to the KI 525/525A.
1.4.4 KA 51/51A/51B SLAVING ACCESSORY
PN BEZEL OBS LIGHTING HDG XMTR
066-3046-00 BLACK 30 HZ 14/28 V
066-3046-01 BLACK 30 HZ 14/28 V X
066-3046-02 BLACK 30/400 HZ 14/28 V
066-3046-03 BLACK 30/400 HZ 14/28 V X
066-3046-04 BLACK 30 HZ 14/28 V
066-3046-05 BLACK 30 HZ 14/28 V X
066-3046-06 BLACK 30/400 HZ 14/28 V
066-3046-07 BLACK 30/400 HZ 14/28 V X
066-3046-08 BLACK 30 HZ 5 V X
066-3046-10 GRAY 30 HZ 5 V X
066-3046-11 GRAY 30/400 HZ 5 V X
066-3046-12 BLACK 30/400 HZ 5 V X
PN BEZEL LIGHTING OBS HDG XMTR
066-3029-00 BLACK 14/28 VDC 30 HZ
066-3029-01 BLACK 14/28 VDC 30 HZ X
