5. Remove and reinstall the battery in the
correct (+/-) orientation as shown on the
inside of the battery door. (After installing
the battery, close the battery door
securely.) See Fig. 5.
Fig. 4. Installing mounting plate.
Fig. 5. Installing battery.
M19053
MOUNTING
HOLES (2)
MOUNTING
HOOKS (2)
UP
M19054
BATTERY
DOOR
OPEN
