69-1513EF—01 8
• See Fig. 2 for multi-level residence CO
alarm locations.
• Mount the CO alarm on the wall or ceiling.
• Locate the top of the alarm at least 3 ft
(.9 meter) from the floor. See Fig. 3.
• Mount the alarm as close as possible to the
center of a hallway or room.
• Mount the edge of the alarm at least four
inches from any adjoining wall.
Fig. 1. Single-floor residence CO alarm
locations.
FAMILY ROOM
KITCHEN
DINING ROOM
BEDROOM
BEDROOM
M19050
= CARBON MONOXIDE ALARM LOCATION
LIVING ROOM
BEDROOM
