Turn the power OFF and disconnect the air cooler from the power
supply.
Move the unit to a location where it can be drained. Remove the
Water Drain Plug (refer page 7., #17) and allow the tank to empty.
Once the tank is empty, unlock the Latches on both sides and detach
top section of your unit as shown in the figure. Place it vertically on
the floor, be careful not to bend the Water Pick Up Tube that hangs
below the unit.
Refill the water tank with clean water and drain it completely.
Clean the water tank with detergent or a damp cloth and rinse it
thoroughly.
Place the top section of your unit carefully on the tank and lock
the latches.
Refill the water tank with clean water, up to the maximum level.
Plug into the power supply and turn the unit on.
•
•
•
•
•
•
15
CLEANING & MAINTENANCE
Latches
Water Pick Up Tube
Water Drain
Plug
Honeycomb Cooling Media
Carbon Filter
Back Panel
Rear Grill
Removal
Screws
Turn off the unit, and unplug the power cord from wall outlet.
Rotate the unit facing the back panel, and locate the Rear Grill
Removal Screws (refer page 7., #10). Remove the screws with
a screw driver.
Pull the rear grill panel upwards, until it is completely removed.
Now, the Carbon Filter and Honeycomb Cooling Media can be seen.
Clean both the filters with clean cloth to remove all the dust & dirt
particles.
Once the cleaning has been completed, assemble the unit as
described above.
Plug into the power supply and turn unit on.
Cleaning The Filter And Honeycomb Cooling Media
Draining And Cleaning The Water Tank

Honeywell CL30XC Specifications

General

Noise level	- dB
Product color	Silver
Package depth	395 mm
Package width	502 mm
Package height	885 mm
Package weight	13800 g

Weight and Dimensions

Depth	352 mm
Width	458 mm
Height	856 mm
Weight	11300 g
