Hose Connector
USE & OPERATION
CAUTION
Water Inlet (Manually)
Unplug from power when refilling.
Filling With Water
Water can be filled into the air cooler by:
Water Inlet (Manually)
Water / Ice can be put into the tank through the top
opening.There is a hole for water to flow into the tank.
Continuous water supply (Auto Refill)
Connect a garden hose to the continuous water supply inlet.
To refill the water tank, pull out the Water Fill Door located on
the top of the unit (#16 on Page 8) and fill water to the Max, as
indicated on the Water Level Indicator (#8 on Page 8)
Do not fill water above the Max water level mark.
For maximum cooling performance, put ice cubes inside the Ice
Loading Compartment located on the top of the Air Cooler (#1
on Page 8).
11
Water Inlet
Water Fill Door
Ice Loading
Compartment
To Next Page
