Walk Testing the Installation
Activate each sensor to check proper reception by the panel: the sensor serial number is displayed with the
radio level of the reception by the panel.
This test can also be used with other radio devices to check proper registering and radio reception on the
panel
1-REGISTER
2-DEVICES
3-PARAMETERS
4-DATE & TIME
5-SYSTEM DIAG.
6-TRANSM.STATUS
7-RADIO SCAN
8-ABORT
9-SAVE+QUIT
4.6 Closing the Panel
Only after programming/modification can the panel be closed. It can also be secured with a screw.
RADIO SCAN
------------------
S/N .........................
RF
....x/10......................
QUIT (
) AGAIN (OK)
14
English Programming
Dimensions Height: 83mm
Width: 235mm / 295mm depending on cover
Max Depth: 50mm / 56mm
Temperature (CSEI - 11- 10 Standard) Operating: -10°C - +55°C
Storage: -40°C - +70°C
Relative humidity (CSEI - 11- 10 Std) < 85%
Weight (with battery) 1280 g (2822 lb)
Power requirements Typical (Ut): Class I - 230V~ 50Hz, fused (100mA)
Battery Type:
Fault threshold:
4V 3,5Ah max.
3,57 V
Max Depth: 50mm / 56mm
Typical consumption (Ut)
Normal:
Calling :
80 mA
125 mA
with GPRS module
100 mA
270 mA
5. Product Specifications
